Quartz - Timber Single Glazed
Quartz – Timber Single Glazed
Quartz Timber Single Glazed Partitioning Information
Our frameless single glazed timber system provides offices with an elegant touch of nature, bringing earthy undertones to your workspace.
With a profile of 100mm wide x 30mm high, this system can incorporate any of our acoustic doors and enhances the performance along with the aesthetic of the building.
With the option to choose different core woods, you can customise your offices to create an area that fully encapsulates what you’re after.
Compatible With:
- Blinds
- Manifestations
- Graphics
- Switch Glass
- Aluminium Banding
Finishes:
- Timber
Quartz Timber Single Glazed Partitioning Specification
Dimensions:
Height up to 3000mm
Track Width 100mm
Track Height 30mm
Acoustics:
Up to 41dB (Rw)
Structure:
BS5234, BS6180, BS6399
Joints:
Dry Joint
Corners:
Dry Joint
(90, 135 & T)
Deflection Head:
+/-12.5mm / +/-25mm
Door Options:
QuartzGlide
Timber Door
Glass Door
Stile Door
GDS Door
MK2 Door
Profiles & Door Frame:
Timber
Ironmongery:
A wide range of ironmongery can
be supplied with Quartz.
Glass Type:
Toughened – Laminated
Glass Thickness:
10mm – 13.5mm
Options:
Blinds
Manifestations
Graphics
Switch Glass
Aluminium Banding
Finishes:
Timber
British Standards:
Sound Measurement BS EN ISO 140
Sound Rating BS EN ISO 717
Structural Stability BS5234, BS6180, BS6399
