Quartz - Timber Double Glazed
Quartz – Timber Double Glazed
Quartz Timber Double Glazed Partitioning Information
A frameless double glazed timber partitioning system that improves workspaces, creating a natural aesthetic that’s perfect for a modern office.
The profile is 100mm wide x 36mm high and can incorporate our acoustic glass doors, including our QuartzGlide sliding door range.
With an increased acoustic performance, our Quartz Timber double glazed partitions provide offices with sound insulation, creating spaces of focus.
Compatible With:
- Blinds
- Manifestations
- Graphics
- Switch Glass
- Aluminium Banding
Finishes:
- Timber
Quartz Timber Double Glazed Partitioning Specification
Dimensions:
Height up to 3000mm
Track Width 100mm
Track Height 36mm
Acoustics:
Up to 47dB (Rw)
Structure:
BS5234, BS6180, BS6399
Joints:
Dry Joint
Corners:
Dry Joint
(90, 135 & T)
Deflection Head:
+/-12.5mm / +/-25mm
Door Options:
QuartzGlide
Timber Door
Glass Door
Stile Door
GDS Door
MK2 Door
Profiles & Door Frame:
Timber
Ironmongery:
A wide range of ironmongery can
be supplied with Quartz.
Glass Type:
Toughened – Laminated
Glass Thickness:
10mm – 13.5mm
Options:
Blinds
Manifestations
Graphics
Switch Glass
Aluminium Banding
Finishes:
Timber
British Standards:
Sound Measurement BS EN ISO 140
Sound Rating BS EN ISO 717
Structural Stability BS5234, BS6180, BS6399
